Page 8 - March-April2021 Vol 38 No 7
P. 8
TDOT’s I-440 Reconstruction I-440 over I-65 Bridge Widening 3.6% superelevation, which precluded
One of the more significant aspects combining the two structures into one
from page 7 and further compounded the design
of the project involved the widening and construction. The existing bridges
The rubblization process greatly of the twin bridges on the fourth level were built with steel tub girders. The
decreased the amount of debris that of the I-440/I-65 interchange, which proposed design called for the addition
needed to be hauled off-site or directed also crosses Franklin Road and CSX of continuous steel plate girder pairs for
toward landfills. It also significantly railroad. The bridges are over 1000 feet each bridge.
reduced the number of trucks leaving in length (with a span arrangement of
the construction site and subsequently 115-166-282-205-160-102 feet), with Due to location constraints, it was
creating traffic congestion issues only a 32-foot gap between them. The determined by the DB Team that the
on other roadways. The contractor bridge reaches a maximum height of 80 use of cranes at this location would not
estimated reducing the number of feet over I-65 mainline lanes. be optimal. Innovative rolling gantry
truckloads of import/export materials cranes were utilized to place rebar
by 25,000. The alignment of I-440 at this location cages for the drilled shafts and pier
is curved with a radius of 3,820 feet and columns, and to lift girder pairs from
the roadway median to place them on
A Full Color Dynamic Message Sign introduces the newly reconstructed, and much smoother riding, I-440 the substructures.
©Eric Brown/TDOT Work at this interchange was
constrained for MOT with only a few
Grand opening events adopted a caravan parade due to COVID-19 ©Eric Brown/TDOT weekends allowed for closures of the
8 TPW March/April 2021 interchange. Girder erection schemes
allowed much of the girder fit-up to
occur off the bridge, thus limiting the
amount of time required when a full
closure was needed.
Project Completed during COVID
A ribbon-cutting ceremony to mark
the re-opening of the roadway was held
in July 2020, a month ahead of schedule.
“The I-440 project is a perfect example
of the importance of investing in our
infrastructure,” Tennessee Governor
Bill Lee said during the grand opening
event. “This roadway is a vital part
of Nashville and Middle Tennessee’s
transportation system, and it now will
be capable of serving this community
for decades to come.”
Due to COVID-19, the ceremony
to celebrate the opening of the
reconstructed highway was modified
from traditional grand opening events; a
60-vehicle caravan paraded through the
project corridor while being escorted
by TDOT HELP Trucks. Vendors and
contractors were staged along the route
to celebrate the achievements for all
involved.
COVID-19 has lessened the
anticipated impact of the reconstruction
project as traffic volumes have not yet
returned to normal levels. However,
early feedback is that the smoother
ride is greatly appreciated, and the two
additional lanes have improved free flow
vehicle movement along the new stretch
of highway.
